Architecture overview

1.1 Overview

Table 1. Describe component in AI service architecture

With a basic AI problem: AI service will require a minimum of 6 components (docker container). The number of components will increase when the AI ​​problem is complex and needs to be divided into multiple stages for processing

Examples for simple AI problems: Person detection, face detection, face embedding, face searching… For each problem like this, 6 components need to be developed and deployed

For more complex problems such as face recognition, it needs to be processed through many steps: face detection, then face embedding and finally searching. There are up to 3 stages in this problem, so there will be up to 3 AI services. Therefore, the number of components that need to be developed and deployed is 10 (add 2 components for each added service)

1.2 AudioCraft service

Audio Craft is an AI service that generates sounds and music based on user descriptions. It is divided into 2 sub-services that operate independently of each other. The AudioGen is used for generating sounds such as: car horns, cat meowing... and the MusicGen specializes in generating music (with melody). AudioCraft's system design is shown in the figure 2

Table 2. Description of sequence diagram and executable code in source code

Table 3. Description of sequence diagram and executable code in source code

Table 4. Description of sequence diagram and executable code in source code

2. Package

2.1 Docker image

2.2 Build docker image

Step 1: Clone the project

$ git clone https://github.com/DopikAI-Labs/aimarket-audiocraft-service.git
# The Git repository URL may change when delivering the source code to the customer. Carefully check the provided URL.

Step 2: Update submodule

$ cd aimarket-audiocraft-service
$ submodule update --init --recursive

If the source code provided is a compressed file, skip the above two steps

Step 3: Build image

Edit script: ./scripts/build_dockerfile.sh

Update the ECR, and version in ./version.json

#!/bin/bash

ECR="your_registry_url/your_repo"
TAG=$(jq -r '.api_version' version.json)
SERVICE="audio_craft"
IMAGE_NAME="${ECR}:${SERVICE}_${TAG}"

docker build -t $IMAGE_NAME -f dockerfile .

echo  image $IMAGE_NAME is built

$ cd aimarket-audiocraft-service

Build image

$ chmod +x ./scripts/build_dockerfile.sh
$ ./scripts/build_dockerfile.sh

If no errors occur, the terminal will show

$ your_registry_url/your_repo:audio_craft_0.1.4 is built

Step 4: Push image to registry

Step 4.1: Login to registry

Install awscli

$ pip install awscli
# or pip3 install awscli
# If you're using a virtual environment created with venv or conda, make sure it's activated before proceeding.

Configure AWS information

$ aws configure
# AWS Access Key ID [None]: Enter your access key ID
# AWS Secret Access Key [None]: Enter your secret  access key
# Default region name [None]: Enter region
# Default output format [None]: Can skip it

For the next time, there is no need to do the above 2 steps in step 4.1 section

Get the password

$ aws ecr get-login-password
# The terminal will generate a string (password)

Login repository: Make sure repository has been created

$ docker login -u AWS -p <<generated_string_from_above_command>> <<repository_URL_in_ECR>>

Step 4.2: Push docker image

Push docker image

$ docker push docker_image_name:tag

3. Deployment

3.1 Infrastructure requirements

3.2 Deployment procedure

Step 1: Pull docker image

Step 1.1 Login registry

Do the same as step 4.1 in the package section

Step 1.2 Pull image

$ docker pull docker_image_name:tag
# docker_image_name:tag => It is an pushed image in the package section

Step 2: Deploy service

Make a deployment directory

$ cd ../../../deployment_space_dirctory_path
$ mkdir audio_craft
$ cd audio_craft
$ mkdir v0.1.4
$ cd v0.1.4
# v0.1.4: Change to match the version to be deployed

Create a docker-compose.yml file

$ vim docker-compose.yml
# Copy ./aimarket-audiocraft-service/docker-compose.yml and past to it

Create .env file

$ vim .env
# Copy ./aimarket-audiocraft-service/.env and past to it

With the .env file, all environment variables highlighted in red need to be updated.

Run service

# make sure you are in the same directory with docker-compose.yml file
$ docker-compose up

Check the terminal to determine if any errors occurred. If not, Ctrl + C to stop running service

Run service in detached mode

$ docker-compose up -d
